CarStopper 30 Bollard.

CODE:

Quantity

CarStopper 30 is a high-security shallow-mount bollard system engineered to stop a 1.5T car travelling at 48kph from breaching a protected perimeter.

With a market-leading 200mm shallow foundation depth, it provides an effective security solution while minimising disruption to underground utilities and reducing installation costs.

Its advanced spring-loaded design allows the bollard to return to position after low-level impacts, reducing ongoing maintenance.

Ideal for retail shopfronts, banks, ATMs, stadiums, and public spaces, combines robust protection with a clean, low-maintenance finish.

More info

Key Features

Shallow mount removable bollard system with only 200mm foundation depth
Designed to protect critical assets from vehicle impact
Suitable for retail shopfronts, banks, sports stadiums, ATMs, and public environments
Can be installed as a single bollard or in continuous runs
Innovative spring-loaded design returns to original position after low impacts
Reduces the need for costly utility relocations or re-diversion work
Compact system design enables fast, straightforward installation
Helps minimise overall installation costs
Removable bollard design allows easy access for maintenance or service areas
Stainless steel shroud provides a clean, aesthetically pleasing appearance
Low-maintenance solution once installed

Technical Specifications

Height above ground: 950mm
Footing Depth: 200mm
Options: Stainless steel & mild steel shroud available

Testing & Certification

Performance tested for Anti-Terrorist protection so provides assured high performance Hostile Vehicle Mitigation.

Crash rated at Mira, in accordance with BSI PAS 68:2010 and CEN, CWA 16221, vehicle performance classification
Tested as a single bollard
Rated Diameter of 110mm round shroud to cover internal spring
