TruckStopper 7-40 Bollard.
CODE:
The TruckStopper 7-40 is a high-security shallow-mount bollard system engineered to stop a 7.5T truck travelling at 64kph from breaching a protected perimeter.
With only a 200mm foundation depth, it delivers exceptional vehicle mitigation performance while reducing installation complexity and disruption to underground services.
Features a lightweight removable assembly and replaceable post system that allows damaged bollards to be swapped out without replacing the concrete foundation.
Its compact, aesthetically pleasing design also makes it one of the most economical high-security bollard systems on the market.
Idea for protecting critical infrastructure such as airports, sports arenas, police stations, government buildings, conference centres.
Key Features
- Shallow footing technology with only 200mm foundation depth
- Lightweight base plate and post assembly — heaviest component only 46kg
- Minimises the need for costly underground utility re-diversion
- Removable bollard design allows access when required
- Bollards can be removed and replaced in minutes if damaged after impact
- Damaged posts can be replaced without removing or replacing the concrete foundation
- Designed to follow ground contours and continue around corners
- Compact system enables easier and more efficient installation
- Economical alternative to traditional deep-footing security bollards
- Aesthetically pleasing finish suitable for public and commercial environments
- Optional mild steel or stainless steel shrouds available
- Low ongoing maintenance requirements
Technical Specifications
- Height above ground: 900mm
- Footing Depth: 200mm
- Options: Stainless steel & mild steel shroud available
Testings & Certification
- High-security bollard system engineered to stop a 7.5-tonne truck at 40mph (64kph) at 90° impact
- Crash rated for 45° impact by a 7.2-tonne truck at 40mph (64kph) with minimal penetration as a triple assembly configuration
- Performance rating: V/7500[N2]/64/90:7.1/14.8
- Tested as a single bollard
