Slowstop® Bollard – 168mm Dia.
CODE:
Impact resistance: 26.7 kJ
SlowStop Bollards are the world’s only full steel rebounding bollard designed to do far more than just block access.
The 168mm is the strongest surface mount bollard on the market. It’s revolutionary steel pipe design is built to absorb impacts up to 26.7 kJ, ideal for maximum protection in the most demanding applications such as large trucks and heavy forklifts.
Reduce damage. Stop repairing and replacing bollards. Also available in 101mm and 141mm diameters.
Key Features
- Protect buildings, assets, vehicles, and pedestrians from damaging collisions
- Ideal for heavy applications such as delivery trucks, heavy forklifts, and even lorries
- Bollard Kit comes with everything needed to install (including anchors)
- Durable yellow powder coat with a C5i corrosion rating and topped with a black cap
- Made in USA – backed by a 2 year warranty
Testing & Certification
- Stops 3T at 10.6 km/h up to 35T at 3.1 km/h without damage
- Impact Rating: 26.7 kJ | 147.3 kN
Technical Specifications
- Diameter: 171mm (7mm wall)
- Height: 1000mm
- Colour: RAL 1023 Yellow Pipe on RAL 9005 Black Pedestal
- Temperature Rating: -40°C to 70°C
- Pipe Coating: EN-ISO 1461 Galvanised + Polyester Powder Coating
- Base Coating: Environmentally Friendly Water-based KTL Coating + Polyester Powder Coat C51 corrosion resistance
- Set Screws: 8 x (M16 x 2.00, 8mm Hex)
- Anchor Screws: 8 (M16 x 140mm Anka Screws)
- Cap: Black Plastic
Options
Videos
Spec Sheets
Rating Table
Options
Videos
SlowStop Bollard | Overview
SlowStop Bollard | Impact Test
SlowStop Bollard | Installation Guide
Spec Sheets
Rating Table
FAQs.
How do SlowStop bollards work?
What applications are these suitable for?
What weight and speed can be absorbed?
How far apart should I install the bollards?
